SNV-GT3033TT - ica.id

Solar Solar Inverters

SNV-GT3033TT

30kW | TRIPLE MPPT

Penggunaan inverter On-Grid untuk mengubah arus DC dari panel surya menjadi arus AC. Inverter ini terangkai dalam sistem On-Grid dimana area tersebut harus terhubung dengan jaringan PLN yang ada, dan tanpa menggunaan baterai/aki.

Key Features

Max. PV Voltage up to 1100V

DC power up to 1.35 ratio

Type II DC / AC SPD

DC / AC Ratio up to 1.5

IP66 protection

Compatible for big capacity PV panel

Zero Export Control (with Power Meter), Optional

High efficiency up to 98.7%

Smaller and lighter

Specification

Nominal AC Output Power (kW)

:

30 kW

Max. PV Input DC Voltage

:

1100 Vdc

MPPT Voltage Range

:

200V – 1000V

Number of MPPT

:

Strings per MPPT

:

Phase

:

3-Phase

Dimension (DxWxH)

:

380 x 483 x 223mm

Net Weight

:

25.5Kg

INPUT (DC)

:

Nominal voltage

:

620Vdc

Start voltage

:

250V

Max. input current per MPPT

:

30A

Max. short-circuit current per MPPT

:

40A

OUTPUT (AC)

:

Max. AC output power

:

33kVA

Nominal AC voltage

:

400V 3L+N+PE

AC grid frequency range

:

50Hz / 60Hz ±5Hz

Max. output current

:

47.8A

Power factor (cos Φ)

:

0.8 leading to 0.8 lagging

THDI

:

<3%

EFFICIENCY

:

Max efficiency

:

98.70%

Euro efficiency

:

98.40%

PROTECTION DEVICE

:

DC switch

:

Yes

Output over current protection

:

Yes

Anti-islanding protection

:

Yes

DC reverse polarity protection

:

Yes

String fault Detection

:

Yes

DC/AC surge protection

:

Type II

Insulation detection

:

Yes

AC short circuit protection

:

Yes

GENERAL SPECIFICATION

:

Operating temperature range

:

-25°C~+60°C

Cooling type

:

Fan cooling

Max. operation altitude

:

4000m

Max. operation humidity

:

0 – 100% (no condensation)

AC output terminal type

:

Quick connector

IP class

:

IP66

Topology

:

Transformerless

Communication Interface

:

RS485 standard, WiFi or Ethernet (optional)

Display

:

LCD

Certification & Standard

:

EN/IEC62109-1; EN/IEC62109-2; IEC/EN 61000-6-1; IEC/EN 61000-6-3; IEC/EN61000-6-2; IEC/EN61000-6-4; IEC61683; IEC60068; IEC60529; IEC62116; IEC61727;EN50549-1; NCRfG; NRS 097; VDE-AR-N-4105; VDE0126; CEI0-21; C10/C11
