8.5 ~ 32VDC

100V (at minimum operating environment temperature); 92V (at 25°C environment temperature)

6.6A

(Max battery voltage + 2V) ~ 80V

80V

100V

≤2%

Lead acid battery: Sealed (default)/Gel/Flooded/User; Lithium battery: LiFePO4/Li-NiCoMn/User

Equalize Charging Voltage : Sealed: 14.6V: Flooded: 14.8V: User: 9-17V (24V system x 2)
Boost Charging Voltage : Sealed: 14.4V; Gel:14.2V; Flooded: 14.6V; User: 9-17V (24V system x 2)
Float Charging Voltage : Sealed/Gel/Flooded:13.8V; User: 9-17V (24V system x 2)
Low Voltage Reconnect Voltage: Sealed/Gel/Flooded: 12.6V; User: 9-17V (24V system x 2)
Low Voltage Disconnect Voltage : Sealed/Gel/Flooded:11.1V; User: 9-17V (24V system x 2)

Boost Charging Voltage : LiFePO4(4s) 14.5V; Li-NiCoMn(3s): 12.5V; User:9-17V (24V system x 2)
Low Voltage Reconnect Voltage : LiFePO4(4s):12.8V; Li-NiCoMn(3s): 10.5V; User: 9-17V (24V system x 2)
Low Voltage Disconnect Voltage : LiFePO4(4s):11.1V; Li-NiCoMn(3s): 9.3V; User: 9-17V (24V system x 2)

≤15mA/12V; ≤22mA/24V

IR communication

-40°C – +60°C

IP68 (1.5m.72h)

Φ3.5mm

120 x 94mm

PV/BAT: 12AWG (4mm²); LOAD: 16AWG (1.5mm²)
