High customer value - Best partner of 1P tracker, with highest utilization of tracker length
- Low voltage design with higher string power, eectively reducing BOS (Balance of System) and LCOE (Levelized Cost of Energy) by 1%~5%
- Standardized module size with higher container space utilization effectively reduces the freight cost
- Excellent compatibility with existing mainstream system components
- Certifed Low-Carbon Footprint
High power up to 625W - Up to 23.1% module efficiency , on 210 innovation platform
- Patented i-TOPCon technology with continuous efficiency upgrade, including contact resistance reduction, rear reflection enhancement and edge quality repairment
High reliability - Minimized micro-cracks with innovative non-destructive cutting technology and high-density packaging
- Reduced risks of hot-spot with half-cut technology
- Certified high resistance against salt, ammonia, sand, PID, LID, LeTID
- Sustainable in harsh environments and extreme weather conditions
High energy yield - Excellent low irradiation performance, validated by 3rd party
- Lower temperature coeficient (-0.29%/°C)
- Higher bifaciality, with up to 10%~20% additional power gain from back side depending on albedo
- Reliable dual-glass structure with 30-year power guarantee
Specification
Peak Power Watts-PMAX(Wp)*
:
STC : 625 NOCT : 478
Power Tolerance-PMAX(W)
:
0 ~ +5
Maximum Power Voltage-VMPP (V)
:
STC : 41.7 NOCT : 39.1
Maximum Power Current-IMPP (A)
:
STC : 15.00 NOCT : 12.21
Open Circuit Voltage-VOC (V)
:
STC : 49.9 NOCT : 47.3
Short Circuit Current-ISC (A)
:
STC : 15.92 NOCT : 12.83
Module Efficiency (%)
:
23.1
Backside Power Gain
:
STC : 5% NOCT : 10%
Peak Power Watts-PMAX(Wp)
:
STC : 656 NOCT : 688
Maximum Power Voltage-VMPP (V)
:
STC : 41.7 NOCT : 41.7
Maximum Power Current-IMPP (A)
:
STC : 15.75 NOCT : 16.50
Open Circuit Voltage-VOC (V)
:
STC : 49.9 NOCT : 49.9
Short Circuit Current-ISC (A)
:
STC : 16.72 NOCT : 17.51
NOCT (Nominal Operating Cell Temperature)
:
43°C(±2°C)
Temperature Coefficient of PMAX
:
– 0.29% /°C
Temperature Coefficient of VOC
:
– 0.24% /°C
Temperature Coefficient of ISC
:
0.04% /°C
Operating Temperature
:
-40~+85°C
Maximum System Voltage
:
1500V DC (IEC); 1500V DC (UL)
Max Series Fuse Rating
:
35A
Key Features
High customer value - Best partner of 1P tracker, with highest utilization of tracker length
- Low voltage design with higher string power, eectively reducing BOS (Balance of System) and LCOE (Levelized Cost of Energy) by 1%~5%
- Standardized module size with higher container space utilization effectively reduces the freight cost
- Excellent compatibility with existing mainstream system components
- Certifed Low-Carbon Footprint
High power up to 625W - Up to 23.1% module efficiency , on 210 innovation platform
- Patented i-TOPCon technology with continuous efficiency upgrade, including contact resistance reduction, rear reflection enhancement and edge quality repairment
High reliability - Minimized micro-cracks with innovative non-destructive cutting technology and high-density packaging
- Reduced risks of hot-spot with half-cut technology
- Certified high resistance against salt, ammonia, sand, PID, LID, LeTID
- Sustainable in harsh environments and extreme weather conditions
High energy yield - Excellent low irradiation performance, validated by 3rd party
- Lower temperature coeficient (-0.29%/°C)
- Higher bifaciality, with up to 10%~20% additional power gain from back side depending on albedo
- Reliable dual-glass structure with 30-year power guarantee
